Tyre pyrolysis plant design description in details

Tyre pyrolysis plant design product introduction

Update Time:2018/3/30  |   Pyrolysis plant

Tyre pyrolysis plant design
Tyre pyrolysis plant design product photo

Payment & Shipping Terms:

FOB Price
  • Min Order
  • Shipping Port
  • Delivery Time
  • Payment Terms
  • Supply Ability
US $ / Set
  • 1 Set/Sets
  • QingDao
  • 15days
  • T/T
  • 30sets/month

tyre pyrolysis plant design

Tyre pyrolysis plant

The tyre pyrolysis plant designed to turn waste plastic/tyre to fuel oil ,carbon black and carbon black. As a professional manufacturer of tyre pyrolysis plant design, tyre pyrolysis plants with the special design and good performance, which make them become more and more popular in the domestic and foreign markets.


1. Tyre Pyrolysis plant Reactor

tyre pyrolysis plant

Tyre Pyrolysis plant Reactor

It is the most important part of the tyre pyrolysis plant, because it is the place where pyrolysis process takes place. Our reactor is made from Q345R steel, which can avoid it being burnt through, thus the service life of the reactor is longer. In addition, the reactor of batch and semi-continuous plastic waste pyrolysis plant is rotary, but for the fully continuous pyrolysis plant, the reactor is fixed. So the heating efficiency and working efficiency can be increased basing on the different capacity.


2. Condenser

tyre pyrolysis plant

Condenser

The new-type tubular condenser has the features of larger cooling area and better cooling effect. So it can improve the oil yield efficiency.

3. Dedusting System

pyrolysis plant design

Dedusting System

It mainly includes water sprayer, ceramic ring filter and washing chamber. It can remove the dust, dioxin and other component in the combustible gas, then the gas can be recycled to heat the reactor. Thus you can save a lot of energy cost. For the exhaust gas produced by burning the fuel, it can also be purified by the de-dusting system before emission.

5. Safety device

pyrolysis plant

Safety device

The tyre pyrolysis plant is equipped with advanced safety devices, such as over temperature and pressure alarm system, auto pressure releasing system, protecting shell, fire fighting devices and so on, all of which can ensure the plant can work in a safe condition. At the same time, it can also protect the workers.

6. PLC Controlling System

pyrolysis plant

PLC Controlling System

It can achieve intelligent operation and avoid the mistakes caused by manual operation.

7. Various model

Doing tyre pyrolysis plants for sale are variuous in model. So the choice is flexible basing on the amount of the waste and the budget.



Technical parameter of tyre pyrolysis plant design
  Items Contents
1 Equipment type DY-1-6 DY-1-8 DY-1-10
2 Raw material waste tyre, waste plastic, waste rubber,
3 Structural form Horizontal rotation Horizontal rotation Horizontal rotation
4 24-hour Capacity 6 ton 8 ton 10 ton
5 Oil yield 2.7-3.3ton 3.6 -4.4ton 4.5 -5.5ton
6 Operating pressure Normal Normal Normal
7 Material of pyrolysis Reactor Q245R Q245R Q245R
8 Thickness of pyrolysis Reactor 16mm 16mm 16mm
9 Rotate speed of pyrolysis Reactor 0.4turn/minute 0.4turn/minute 0.4turn/minute
10 Total power 19KW 19KW 19KW
11 Mode of cooling Water cooling Water cooling Water cooling
12 Cooling area of condenser 100sqm 100sqm 100sqm
13 Kind of transmission Internal gear drive Internal gear drive Internal gear drive
14 Noise dB(A) ≤85 ≤85 ≤85
15 Size of Reactor(D×L) 2200×6000 2200×6600 2600×6600
16 Working form Intermittent operation Intermittent operation Intermittent operation
17 Delivery time 20days 20days 20days
18 Weight 27T 30T 35T
  • 1.China Suppliers of tyre pyrolysis plant design,sale tyre pyrolysis plant design.provide client tyre pyrolysis plant design designs.
  • 2.No pollution to environment with emission report to meet international environment standard.
  • 3.Provide tyre pyrolysis plant design project report ,financial analysis and tyre pyrolysis plant design cost to clients.
  • 4.Send engineer Installation tyre pyrolysis plant design,training workers to operate machine.
  • 1.High oil yield;no bad smell during process.
  • 2.Enough safety systems;normal pressure.
  • 3.Recycled tail gas to heating tyre pyrolysis plant design;no waste emission.
  • 4.Auto welding to ensure tyre pyrolysis plant design life, service life will be 8-10years.
  • 5.Excellent service(pre-service,selling service,after-sale-service).
Average oil yield from Tyre pyrolysis plant design :
waste tyre to oil 45%
waste plastic to oil 60%
waste rubber to oil 75%
More details about waste tyre, waste plastic, waste rubber, oil yield
